    SON H 350W/220 E40 1SL/12

    SON H 350W/220 E40 1SL/12

    Full Product Code: 871150018213515

    Order code: 18213515

    Downloads

    Leaflet
    Size:2.4 MB
    Leaflet
    Size:2.4 MB

    See all downloads

Видеоклипове

[trigger to render Video Gallery]

Изображения

Specifications Show all

General Information
Cap-Base
E40  [ E40]
Operating Position
UNIVERSAL  [ Any or Universal (U)]
Life To 5% Failures (Nom)
9000 h
Life To 10% Failures (Nom)
12000 h
Life To 20% Failures (Nom)
16000 h
Life To 50% Failures (Nom)
26000 h
System Description
na  [ -]
LSF 2000 h Rated
99 %
LSF 4000 h Rated
99 %
LSF 6000 h Rated
98 %
LSF 8000 h Rated
96 %
LSF 12000 h Rated
90 %
LSF 16000 h Rated
81 %
LSF 20000 h Rated
69 %
Light Technical
Colour Code
220  [ CCT of 2000K]
Luminous Flux (Rated) (Nom)
34000 lm
Chromaticity Coordinate X (Nom)
525
Chromaticity Coordinate Y (Nom)
415
Colour Temperature, horizontal (Nom)
2000 K
Luminous Efficacy (rated) (Nom)
98 lm/W
Colour Rendering Index horiz (Max)
25
Depreciation 2000 hrs
98 %
LLMF 4000 h Rated
96 %
Depreciation 5000 hrs
95 %
LLMF 8000 h Rated
93 %
LLMF 12000 h Rated
90 %
LLMF 16000 h Rated
87 %
LLMF 20000 h Rated
84 %
Ratio Scotopic/Photopic Lumens
0.60
Operating and Electrical
Lamp supply voltage
220 V  [ 220]
Power (Rated) (Nom)
350.0 W
Lamp Current (EM) (Nom)
3.6 A
Ignition Supply Voltage (Max)
190 V
Re-Ignition Time (Min) (Max)
180 s
Ignition Time (Max)
10 s
Voltage (Max)
129 V
Voltage (Min)
105 V
Voltage (Nom)
117 V
Controls and Dimming
Dimmable
No
Run-up Time 90% (Max)
5 min
Mechanical and Housing
Bulb Finish
Coated  [ Coated glass (CO)]
Approval and Application
Energy Efficiency Label
A+
Mercury (Hg) Content (Nom)
28.6 mg
Energy Consumption kWh/1000 h
385 kWh
Luminaire Design Requirements
Bulb Temperature (Max)
350 °C
Cap-Base Temperature (Max)
250 °C
Product Data
Full product code
871150018213515
Order product name
SON H 350W/220 E40 1SL/12
EAN/UPC - Product
8711500182135
Order code
18213515
Numerator - Quantity Per Pack
1
Numerator - Packs per outer box
12
Material Nr. (12NC)
928153509830
Net Weight (Piece)
0.236 kg
ILCOS Code
SEQ-350-H-E40
Installation Diagrams
SON H, E27/E40
SON H, E27/E40
E40
E40
Performance Diagrams
SON H
SON H
SON H 220 W, 350 W Lumen Maintenance
SON H 220 W, 350 W Lumen Maintenance
SON H 200 W, 350 W Service Lifetime
SON H 200 W, 350 W Service Lifetime
SON H 220 W, 350 W Life Expectancy
SON H 220 W, 350 W Life Expectancy
Photometrics
SON H
SON H
