        Product family information

        CoreLine tempo small is a highly efficient range of luminaires designed for 1:1 retrofit replacement of conventional technology, while retaining the same electrical installation and poles. It offers lower power consumption and requires less investment than conventional installations. A limited range of options makes it easy to find the best lux-for-lux replacement.The easy-to-install CoreLie tempo small offers a system flux that covers many different application areas and it comes with both high-performance asymmetrical and symmetrical optics.

        Benefits

        Fast payback:energy savings
        Low-maintenance thanks to the long lifetime of the luminaire
        simple to install and connect
        Robust, high-quality finish
        Equipped with Service tag, a QR-based identification system that makes each luminaire uniquely identifiable and provides maintenance, installation and spare part information

        Features

        Highly efficient : up to 110 lm/W
        Designed for 1:1 retrofit replacement of conventional technology up to 70W HID
        Long lifetime of 75Khrs L80 at Tq +25 ºC
        System flux : 4200 lm
        High-performance asymmetrical and symmetrical optics
        External quick 3-pole IP68 connector
        High surge protection : 10 kV

        Applications

        Bilboards/advertising lighting
        Landscape features
        Security and amenity lighting
        General lighting
        Downloads
        Leaflets
        Visuals
        Software Plugins
        Product family details
        General
        Type
        • BVP110
        Light source
        • Integral LED-module
        Power
        • 38 W (+/-10 %)
        Luminous flux
        • 4200 lm
        Luminaire efficacy
        • 110 lm/W
        Correlated Color Temperature
        • 4000 K
        Color Rendering Index
        • >80
        Lumen maintenance at median useful life* 75000 h
        • min L80
        Control gear failure rate at median useful life 75000 h
        • 7.5%
        Performance Ambient Temperature Tq
        • +25 ºC
        Driver
        • Built-in (self-ballasted LED-module)
        Mains voltage
        • 220-240 V / 50-60 Hz
        Inrush current
        • 5 A / 0.06 ms
        Dimming
        • No
        Controls system input
        • No
        Options
        • No
        Optic
        • Symmetrical
        • Asymmetrical
        Optical element
        • Metachylate optical lens
        Optical cover
        • Clear glass, flat
        Material
        • Housing: die-cast aluminum
        Color
        • RAL9007 matt
        Connection
        • External IP68 quick connector (3 pole)
        Maintenance
        • No internal cleaning required
        Installation
        • U-shaped mounting bracket with foot-print suitable for 3-point fixation by means of M20 bolts
        • Standing-up or hanging-down mounting
        • U-bracket stirrup with standard bolts and nuts
        • Protractor scale with intervals of 5º
        • Mains M20 cable gland that accept cable diameters from 10 to 14 mm with external Quick 3 poles IP68 connector
        • No need to open the luminaire for electrical connection
        Operating temperature
        • -30ºC < Ta < 35ºC
        Projected area in horizontal position
        • At 90º, 0.052 m²
        Max adjustment from the horizontal
        • -170 to +170º
        Max vertical aiming
        • -90 to +90º
        Cable gland
        • M 20
