    • PrimaVision Power (100W & 150W) for CDM - High power packed in a small size

      HID-PV C 150 /S CDM 220-240V 50/60Hz
      HID-PV C 150 /S CDM 220-240V 50/60Hz

      HID-PV C 150 /S CDM 220-240V 50/60Hz

      Order code: 91052330

      Full Product Code: 871150091052330

    Specifications Show all

    General Information
    Lamp Type
    CDM
    Number of Lamps
    1 piece/unit
    Suitable For Outdoor Use
    No
    Number of Products on MCB (16A Type B) (Nom)
    6
    Automatic Restart
    Yes
    Operating and Electrical
    Input Voltage
    220 to 240 V
    Input Frequency
    50 to 60 Hz
    Operating Frequency (Nom)
    0.14 kHz
    Power Factor 100% Load (Nom)
    0.95
    Ignition Voltage (Max)
    5.0 kV
    Ignition Switch-Off Time (Nom)
    20 min
    Mains Voltage Performance (AC)
    -10%-+6%
    Mains Voltage Safety (AC)
    -18%-+10%
    Earth Leakage Current (Max)
    0.35 mA
    Inrush Current Width
    .50 ms
    Constant Wattage Deviation
    -3%/+3%
    Power Losses (Nom)
    10 W
    Inrush Current Peak (Max)
    50 A
    Wiring
    Cable Capacity Output Wires Mutual (Nom)
    200 pF
    Cable Length From Device to Lamp
    2.0 m
    Wire Striplength
    10.0-11.0 mm
    Ballast Contact Wire Cross Section
    0.50-2.50 mm²
    Connector Type
    Insert
    System characteristics
    Rated Ballast-Lamp Power
    150 W
    Temperature
    T-Ambient (Max)
    60 °C
    T-Ambient (Min)
    -20 °C
    T-Storage (Max)
    85 °C
    T-Storage (Min)
    -25 °C
    T-Case Lifetime (Nom)
    75 °C
    T-Case Maximum (Max)
    85 °C
    Mechanical and Housing
    Housing
    /S
    Approval and Application
    Active Temperature Protection
    Yes
    EMI 9 kHz ... 300 MHz
    CISPR 15 ed 7.2
    Vibration Standard
    IEC60068-2-6 F c
    Bumps Standard
    IEC 60068-2-29 Eb
    Approval Marks
    F-Marking
    CE marking
    VDE certificate
    VDE-EMV certificate
    CB Certificate
    Hum And Noise Level
    Inaudible
    Product Data
    Full product code
    871150091052330
    Order product name
    HID-PV C 150 /S CDM 220-240V 50/60Hz
    EAN/UPC - Product
    8711500910523
    Order code
    91052330
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    12
    Material Nr. (12NC)
    913700614066
    Net Weight (Piece)
    0.360 kg
